Statistics of station Lonsee

Here you can find statistics of the TOA lightning detection station Lonsee.

  • Firmware: 1.7
  • Controller: 10.4
  • Amplifier: 12.3 / 13.1
  • Antenna 1+2: Ferrite rod, length=200mm, diameter=12mm, shielded
  • Antenna 4+5+6: Electric field, length=600mm
  • Website: www.kleinmaeusiges.de
  • Comment: Red PCB 10.3 / PCB 13.1 / PCB 12.3

General statistics of the last hour

  • Station active: yes
  • Last update: 2,453,390.7 minutes ago
  • Last detected stroke: 2021-08-07 14:01:02
  • Strokes: 0
  • Signals: 383
  • Locating ratio: 0.0%
  • Stroke ratio: 0.0%
  • Strokes station min participants: 0 (0.0%)

GPS

Some information about the GPS receiver, which is used for receiving the exact time an position. If known, the antenna bearings are also displayed (red, green).

  • Last position: 48.541695° / 9.924856°

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Lonsee and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Lonsee and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
